| CPU | Rockchip RK3566 Quad-core 64-bit Cortex-A55 GPU Mali-G52 |
| Main frequency | Up to 1.8GHz |
| GPU | ARM Mali-G52 2EE,OpenGL ES 1.1/2.0/3.2,Vulkan 1.1,OpenCL 2.0,Embedded with high performance 2D acceleration hardware. |
| NPU | 1TOPS computing power, support int8/int16 |
| RAM | LPDDR3 1G/2G Optional |
| Built-in storage capacity | EMMC 16G/32G/64G optional |
| Display Interface | HDMI 2.0,MIPI,LVDS,EDP display interface |
| Screen voltage | |
| Touch screen | Provide I2C interface (can support multi-point resistive touch, multi-point capacitive touch)
Support USB multi-point infrared touch, multi-point acoustic touch, multi-point optical touch. |
| Network | With RJ45 interface, support 10/100M Ethernet. With Wifi & BT module, support Wi-Fi 802.11b/g/n protocol. Support BT4.0 |
| Image rotation | Support 0 degrees, 90 degrees, 180 degrees, 270 degrees manual / automatic rotation, support gravity sensing function |
| Real-time clock | Built-in real-time clock powered battery |
| Interface device | Support MIPI interface camera, support up to 500W pixels |
| 4 USB HOST 2.0, 1 USB HOST3.0, 1 USB OTG (support usb camera @ 500W usb printer , USB stick , mouse , keyboard standard usb
peripherals) |
| 2 groups of serial ports, support external serial device modules (NFC modules, printers, card swipes, etc.) |
| TF card, supports up to 32GB |
| Class D amplifier: 3W*2 8 ohms, microphone support |
| Audio | MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP |
| Video | Support H.265/H.26/VP9 video decoding, up to 4K60FPS
Support H.264/H.265 video encoding, up to 4K30FPS |
| Picture | Support JPG, BMP, PNG and other image formats to browse and support rotation / slideshow / image zoom function |
| Power adapter | Input:AC100-240V.50-60HZ, output: DC12V 3A(Internal positive and external negative) |
| Operating system | Android 11 and above |
| Basic software functions | Web browsing, web chat, email, e-book, resource manager |
| Sound mode | lock, alarm clock, calculator, recording |
| Language | multi-lingual |
| recording | Support MP3, WMA format recording |
| Tool | Calendar, Alarm Clock, Calculator, Note, Weather + clock, Recording |
| Word processing | EPUB, WORD, EXCEL, POWERPOINT, PDF, TXT |
| E-book | PDF/TXT/CHM/DOC/EXCEL/EPUB/RTF/FB2 |
| schedule | Calendar |
| Input | Standard Android keyboard, optional third-party input method (Chinese, Korean, Japanese, etc.) |
| Internet | Browser -ChromeLite,GOOGLE Market,Email,Gmail,Google talk |
| System Management | Support OTA remote upgrade, U disk upgrade, SD upgrade (silent installation) |
| Original Android system with open root access for product customization and development |
| Customizable local or remote server management system |
| Support multiple third-party Android remote ad distribution systems |
| Support multi-channel serial devices, USB devices, IO control devices |
